Profile storage warehouse

The three-dimensional material warehouse is a double tower, 17 layers of feed tower and 19 layers of main material tower, with a total of 36 storage locations. The single-storey 470mm bin can store profiles with a diameter of 220mm and a length of 6000mm and below. The rated load capacity of the single-storey bin is 3000kg.

The lifting and lifting of the skip car and the inlet and outlet warehouse are both bilateral synchronous drives, and the lifting speed and the inlet and outlet warehouse speed are 5-11.5M/mm.

In and out of the material platform for mobile skip table size 0.8m*6.7m, rated load 3000kg.
